Basic Info.
| Model NO. | FMP51/FMP57/FMP52/FMP40/FMP42/FMR51/FMR52/FMR20 | Range | 0-30m |
| Measurement Accuracy | ±5mm | Accuracy | 0.2% |
| Kind | Radar | Structure | All in One |
| Warranty | 1 Year | Certification | CE, RoHS |
| Material | SS360L | Process Temperature | -40~120℃ |
| Process Pressure Ure | Vacuum...40 Bar | Max. Measurement Distance | Od: 10 M (33 FT) Min Dk>1.6 Rope: 25 M...30 M |
| Main Wetted Parts | 316L, Alloy C, Ceramic | Process Connection | Thread,Flange |
| Communication | 4...20 Ma Hart Profibus PA Foundation Fieldbus | Transport Package | Carton or Wooden |
| Specification | 0-70m | Trademark | Endress+Hauser |
| Origin | Europe or China | HS Code | 9026100000 |
| Production Capacity | 50000/Year |
Packaging & Delivery
| Package Size | 200.00cm * 26.00cm * 24.00cm |
| Package Gross Weight | 30.000kg |
Levelflex FMP51/FMP57/FMP52/FMP40/FMP42/FMP43
Micropilot M
FMR530/ FMR531/ FMR532/ FMR533/ FMR540
FMR20/ FMR50/ FMR51/ FMR52/ FMR53/ FMR54/ FMR56/ FMR57
FMR60/ FMR62/ FMR67/ FMR60B/ FMR62B/ FMR66B/ FMR67B
FMR230/ FMR231/ FMR240/ FMR244/ FMR245/ FMR250
Field of application: Levelflex FMP50 is designed for basic applications in liquids, ideal for supply, storage, and utility processes. It offers continuous level measurement for liquids, pastes, and slurries, unaffected by changing media, temperature fluctuations, or vapors.
Specifications
Process connections: Thread or adapter flange
Temperature range: -20 to +80°C (-4 to +176°F)
Pressure range: -1 to +6bar (-14.5 to +87psi)
Maximum measuring range: Rod 4m (13ft), rope 12m (39ft)
Accuracy: ±2mm (0.08")
Features
Reliable measurement under changing conditions
HistoROM data management for easy commissioning and maintenance
Multi-Echo Tracking evaluation for highest reliability
IEC 61508 up to SIL3 compliance
Heartbeat Technology for cost-effective plant operation
Seamless integration into control systems
World's easiest proof test for SIL and WHG
| Minimum starting voltage | 17.5 V |
| Start-up current | 4 mA |
| Starting time | 80 s |
| Minimum operating voltage | 17.5V |
| Multidrop current | 4.0 mA |
| Time for connection setup | 30s |
Company: Shenzhen Anyi Technology Co., Ltd.
LevelFlex Liquid Level Gauges
Introducing the LevelFlex series of liquid level gauges from Shenzhen Anyi Technology Co., Ltd. Our products include:
LevelFlex M
FMP50/ FMP51/ FMP52/ FMP53/ FMP54/ FMP55/ FMP56/ FMP57
FMP40/ FMP41C/ FMP43/ FMP45
Micropilot M
FMR530/ FMR531/ FMR532/ FMR533/ FMR540
FMR20/ FMR50/ FMR51/ FMR52/ FMR53/ FMR54/ FMR56/ FMR57
FMR60/ FMR62/ FMR67/ FMR60B/ FMR62B/ FMR66B/ FMR67B
FMR230/ FMR231/ FMR240/ FMR244/ FMR245/ FMR250
Key Features:
Accurate and reliable level measurement
Micro pulse technology for precise readings
Easy installation and setup
Durable construction for long-lasting performance
Whether you need a LevelFlex for industrial or commercial applications, our products deliver exceptional performance and value. Trust Shenzhen Anyi Technology Co., Ltd. for all your liquid level gauge needs.
